i pick up this poor girl recently and it need a lot of work but the monitor and chassis works.

Ask you can see on the pictures , the jamma harness was cut off.
If any one can provide some pictures of the audio jst connector i will be very grateful


Attachments

  • IMG_20200615_233949.jpg
    921 KB · Views: 278
  • IMG_20200615_234017.jpg
    951.8 KB · Views: 225
  • IMG_20200615_234040.jpg
    884.6 KB · Views: 217
  • IMG_20200615_234117.jpg
    971.4 KB · Views: 275

BlinG

Grand Master
Joined
Jul 26, 2017
Messages
844
Reaction score
762
Location
Arizona
I hope you got a tetanus shot before you touched that. Looks like a ton of work and hopefully that tube is still good.. but little at a time I am sure this can have potential.


Elfito69

Student
Joined
Jul 31, 2019
Messages
73
Reaction score
54
Location
San ysidro
I hope you got a tetanus shot before you touched that. Looks like a ton of work and hopefully that tube is still good.. but little at a time I am sure this can have potential.
the tube is good, it was replace by another toshiba whit the same curvature.
The original was fried


AMS

Grand Master
Joined
Mar 28, 2020
Messages
789
Reaction score
637
Location
Amsterdam/Netherlands
I hope you got a tetanus shot before you touched that. Looks like a ton of work and hopefully that tube is still good.. but little at a time I am sure this can have potential.
:thumbsup: :thumbsup: :thumbsup:


Elfito69

Student
Joined
Jul 31, 2019
Messages
73
Reaction score
54
Location
San ysidro
I started whit the bezel because it need more work.
The sun eat through the paint and made small cracks on the plastic, got most of it flatten out but still need to patch that hole


Attachments

  • IMG_20200616_015928.jpg
    975.9 KB · Views: 158
  • IMG_20200616_015326.jpg
    676.2 KB · Views: 144

AMS

Grand Master
Joined
Mar 28, 2020
Messages
789
Reaction score
637
Location
Amsterdam/Netherlands
Better to sand i all down and have the bottom blasted to see what rust is underneath and then repaint the whole thing :)

nice project!


Bluetear

Professional
Joined
Aug 28, 2019
Messages
194
Reaction score
386
Location
USA
Looking forward to watching this restore. Love to see a beautiful E2 brought back to life. Good luck, @Elfito69. And thanks for sharing the awesome (and helpful) restore photos, @Mrhide. Great work. Your skills are very impressive.


hoagtech

Champion
Joined
Mar 28, 2019
Messages
1,348
Reaction score
1,634
Location
Bellingham WA
It looks great.

New graphics cp and paint would go a long way.

You can attach the wires to a new JAMMA female by following each wire to the JAMMA pinout diagram.

Good luck. I would be thrilled to find that in a barn.


Elfito69

Student
Joined
Jul 31, 2019
Messages
73
Reaction score
54
Location
San ysidro
Good luck. I would be thrilled to find that in a barn.
i din't actually found it in a barn, i just named it that because it looks like one of those barn find classic cars :P

The operator did told me that they where on service a long ago and he stored them on a friends back yard, but rain and time got the best of them


Elfito69

Student
Joined
Jul 31, 2019
Messages
73
Reaction score
54
Location
San ysidro
Also was searching for a power supply cap kit but had no luck, so i went ahead and made a list

x1 560uf 180v @ c004
x4 10uf 50v @ c302,c007,c008,c003
x1 33uf 25v @ c015
x1 100uf 50v @ c011
x1 3300uf 10v @ c103
x1 4700uf 10v @ c101
x1 180uf 25v @ c202
x1 560uf 25v @ c301
x1 1000uf 25v @ c201



EDIT:
all caps are available on Digikey

Last edited:
