@evilsim kindly sent me a 3D printed case for a dual Mega Drive Daemonbite so I built it properly. It took a bit of time, I’d say a good hour or two. Can’t recommend it enough. The minimal lag with the M30’s takes MiSTer to a whole other level.



Really wish I used kynar wire in hindsight (it’s a pain to strip though — anyone got any tips).



Not my finest soldering / wiring work but there’s no real need for strain relief so it’s all crammed in there now and works.

My biggest warning to people is to be careful of the USB port on the Arduino. After 10-15 removals, it WILL snap off or become loose. Best to plug your cable in and never remove it from the PCB side.


awbacon1

Champion
Joined
Apr 20, 2019
Messages
1,122
Reaction score
822
Location
Chicago
@evilsim kindly sent me a 3D printed case for a dual Mega Drive Daemonbite so I built it properly. It took a bit of time, I’d say a good hour or two. Can’t recommend it enough. The minimal lag with the M30’s takes MiSTer to a whole other level.



Really wish I used kynar wire in hindsight (it’s a pain to strip though — anyone got any tips).



Not my finest soldering / wiring work but there’s no real need for strain relief so it’s all crammed in there now and works.

My biggest warning to people is to be careful of the USB port on the Arduino. After 10-15 removals, it WILL snap off or become loose. Best to plug your cable in and never remove it from the PCB side.
some good case work


GeorgeSpinner

Enthusiast
Joined
Oct 20, 2020
Messages
235
Reaction score
192
Location
Piscataway NJ USA
@evilsim kindly sent me a 3D printed case for a dual Mega Drive Daemonbite so I built it properly. It took a bit of time, I’d say a good hour or two. Can’t recommend it enough. The minimal lag with the M30’s takes MiSTer to a whole other level.



Really wish I used kynar wire in hindsight (it’s a pain to strip though — anyone got any tips).



Not my finest soldering / wiring work but there’s no real need for strain relief so it’s all crammed in there now and works.

My biggest warning to people is to be careful of the USB port on the Arduino. After 10-15 removals, it WILL snap off or become loose. Best to plug your cable in and never remove it from the PCB side.

Looks great.

Is that fun-tak I see?

Are you using it to hold the lid closed?

If it is - I use the stuff, for purposes like this, all the time as well.

It's an a very handy tool when you need something temporarily affixed.


djsheep

Multi Boyz Overlord
Immortal
Multi Boyz
Joined
May 20, 2016
Messages
6,247
Reaction score
9,653
Location
Brisbane, Australia
Is that fun-tak I see?

Are you using it to hold the lid closed?
It’s called Blu-Tack in Australia, but yep! Using it to hold the Arduino in place as I didn’t trim the case to fit it before I fitted the ports and cabling in the case and didn’t want to break anything! Case is being held together temporarily with tape until I give it a nice burn in. Then I’ll superglue it all together.


benime

Professional
Joined
Aug 8, 2015
Messages
353
Reaction score
467
Location
Portland, OR
I’ll try that method again. The two prior times I tried it, either the insulation was having issues melting or I made a mess of my irons tip.
I usually just melt the insulation and clean my tip with a Hakko 599B (brass wire ball), otherwise I have an old wire wrap tool I bought years ago at Radio Shack similar to this

https://www.amazon.com/JAMECO-BENCHPRO-30AWG-Wire-Wrap/dp/B00C9NWR1Q/

The bottom pops off and the shaft is hollow and contains a strip tool for kynar.
