Hi everyone,
I had a CPS3 motherboard fail on me and I have replaced it, but I recently repaired a CPS3 with a bad SIMM slot and decided to have another look at my own faulty board.

Fault: Game stops writing at 6m24s remaining. Third Strike freezes, other games give error 22

Fix:

I replaced SIMM slot 2 as it was giving the error (the second digit in the error code indicates the slot that is not working correctly) - this did not resolve the issue. Some SIMMS that work on other boards do not register in this slot and trying to test this slot on the board causes it to freeze.

I decided to beep out all pins on the board to see if perhaps a bad trace was causing the system not to be able to read this slot correctly. The custom called CCU (CPU/cartridge Control Unit?) is connected to both SIMM slot 1 and 2, where the main CPU program code is stored. The other slots are all connected to either the PPU (Parallel Processing Unit) or the GLL (Graphics Library ?)



I came across this trace (indicated with the white square) that read to the via on the bottom of the board, but on the top did NOT beep out to the pin on the custom. There is also another trace you can see going to the other custom which looks damaged (yellow square) I beeped it out and it appeared to be working, but more on this later.



Fortunately 30awg Kynar wire was just thin enough to fit through the via. I inserted a piece of wire and soldered it at both ends to create a jumper to replace the via that had corroded. I also used a fibreglass pen to sand back the other corroded looking trace and used solder to reconnect the via to the trace which showed a solid connection to the GLL custom. Here is the top side of the repair



And here is the bottom side


I installed SIMMS back onto the board, inserted a cart and it booted! I let it install Second Impact just to see if it would work and at 6m24s remaining it continued the countdown. Success!



Success! Board repaired!

I was really happy with this but before confirming the board was fixed, I decided to load Third Strike using the SuperBIOS. I tried multiple times to get it to load but was given constant messages of the CD ROM is not connected. My SCSI CD ROM drive then decided to die by eating itself. I opened the drive and the disc did not come out, I tipped the drive up and several small pieces of plastic fell out. It appears a small piece came away from it's original location and got into the drive mechanism, destroying the gears. RIP CD ROM drive.


New fault: CD ROM is not recognised by board consistently, will not read CD properly.

Fix (Part 2):

I got my SCSI2SD (not used originally because it is installed on my main board in a hursit case) and was given the same errors. Occasionally it would load and offer to install 2I, or it would start reading the disc contents and freeze. I then decided to beep out the traces coming from the SCSI 50 pin connector and reflowed all pins on the cartridge slot because the main CPU is in the cartridge. Almost all the traces on the 50 pin connector carrying data connect to some type of controller in the top corner of the board above SIMM slot 1. I thought that this controller may be damaged, but followed the traces from this controller NOT going to the SCSI connector, and noticed they connected to......... the GLL custom.

I followed these traces back and one of them was the trace I had previously thought was damaged connected to GLL



Yep. The trace I hadn't fixed properly the first time when I had seen it looked damaged. So after finding that this was in fact connected to the CD drive, I patched it too.





Once again I loaded the SIMMS and the cart, fired up the board and success! It read the SCSI2SD with no issues immediately. I let it load 3S and:



We have a working CPS3 motherboard!

Lesson learned. If you see a trace that looks like it might be dodgy, double check it.


Murray

Professional
Joined
Oct 8, 2019
Messages
580
Reaction score
556
Location
Oz
Nice writeup! I have a CPS3 motherboard with a bunch of... burnt? traces on the bottom of it... it's in the too hard pile at this stage.

Those traces look a lot bigger in a photo than they actually are!

Haven't got a spare 128mb simm floating around you'd sell do you?


xodaraP

Enlightened
Joined
Sep 21, 2016
Messages
4,414
Reaction score
3,043
Location
Gold Coast, Australia
This one has been in the too hard basket for quite some time, but I decided to give it another look.

I wanted to zoom in to show the fix. I think it turned out pretty well, here's what it looks like now without the zoom:



Future plan is to cover it with solder mask to protect it from future corrosion.

I don't I'm sorry, I had a couple of spare 128mb I sold to others to get up and running and the 1 I have left I'm keeping for my own boards in case I have a failure. I do have a number of 32mb I plan to upgrade to 128mb


Murray

Professional
Joined
Oct 8, 2019
Messages
580
Reaction score
556
Location
Oz
Just sharing for the hell of it.

It's just a spare parts board for now. Maybe one day I will have a crack at it!





Murray

Professional
Joined
Oct 8, 2019
Messages
580
Reaction score
556
Location
Oz
I don't I'm sorry, I had a couple of spare 128mb I sold to others to get up and running and the 1 I have left I'm keeping for my own boards in case I have a failure. I do have a number of 32mb I plan to upgrade to 128mb
All good, thanks anyways!


xodaraP

Enlightened
Joined
Sep 21, 2016
Messages
4,414
Reaction score
3,043
Location
Gold Coast, Australia
They're not burnt, the solder mask has been sanded away by the look of it. That looks like a LOT of corrosion around the SIMMS, I'm guessing that's why. They sanded it back with the intention of fixing what was required or sanding away the corrosion and tinning all the traces.


Murray

Professional
Joined
Oct 8, 2019
Messages
580
Reaction score
556
Location
Oz
They're not burnt, the solder mask has been sanded away by the look of it. That looks like a LOT of corrosion around the SIMMS, I'm guessing that's why. They sanded it back with the intention of fixing what was required or sanding away the corrosion and tinning all the traces.
Yeah, you are probably right! Anyways... back to the too hard pile..... for now :)


xodaraP

Enlightened
Joined
Sep 21, 2016
Messages
4,414
Reaction score
3,043
Location
Gold Coast, Australia
They're not burnt, the solder mask has been sanded away by the look of it. That looks like a LOT of corrosion around the SIMMS, I'm guessing that's why. They sanded it back with the intention of fixing what was required or sanding away the corrosion and tinning all the traces.
Yeah, you are probably right! Anyways... back to the too hard pile..... for now :)
I have one with a number of rusted out customs I'm keeping as a parts donor


mR_CaESaR

Grand Master
Joined
Jul 10, 2018
Messages
571
Reaction score
655
Location
Sydney, Australia
This is great stuff xodaraP!

You know I've been nagging you about mine :D

You can create another worklog for that :)
